BD Angiocath™ IV Catheter 14G (2.1 x 30 mm)

BD Angiocath™ IV Catheter 14G (2.1 x 30 mm)

£3.26
£0.00 £3.26
Sale Sold out
Size
Product overview
  • Peripheral venous catheter
  • Provides peripheral vascular access
  • Excellent penetration properties
  • Easy blood flow detection
  • Recommended for infusion, transfusion & angiography

BD Angiocath™ Peripheral IV Catheter

BD Angiocath™ peripheral IV catheters are designed to provide peripheral vascular access. The needle features a triple-bevel tip, enabling a less painful and atraumatic puncture while providing excellent penetration properties. The catheter is made of high-quality FEP material and includes a transparent flashblck chamber for easy blood flow detection. Recommended for infusion, transfusion and angiography applications, the catheter is fully compatible with BD Luer-Lock connections and available in various configurations. Individually sterile-packed for single use, the BD Angiocath™ catheter is also PVC- and latex-free, ensuring the highest hygiene standards.



Product Details

  • BD Angiocath™ IV Catheter
  • Peripheral venous catheter
  • For peripheral vascular access
  • Needle with a triple-bevel tip
  • Enables less painful and atraumatic punctures
  • Excellent penetration properties
  • Catheter made of FEP material with a clear flashback chamber
  • Easy blood flow detection
  • Compatible with BD Luer-Lok™
  • Recommended for infusion, transfusion, and angiography
  • Available in various configurations
  • Individually sterile-packed single-use product
  • PVC- and latex-free
  • No injection port
  • 1 piece



Ordering Information

Gauge Catheter Length Outer Diameter Flow Rate Colour
24G 19 mm 0.7 mm 17 ml/min Yellow
22G 25 mm 0.9 mm 28 ml/min Blue
20G 30 mm 1.1 mm 49 ml/min Pink
20G 48 mm 1.1 mm 42 ml/min Pink
18G 30 mm 1.3 mm 86 ml/min Green
18G 48 mm 1.3 mm 79 ml/min Green
16G 30 mm 1.7 mm 156 ml/min Grey
16G 48 mm 1.7 mm 147 ml/min Grey
16G 83 mm 1.7 mm 127 ml/min Grey
16G 133 mm 1.7 mm 108 ml/min Grey
14G 30 mm 2.1 mm 295 ml/min Orange
14G 48 mm 2.1 mm 277 ml/min Orange
14G 83 mm 2.1 mm 249 ml/min Orange
14G 133 mm 2.1 mm 219 ml/min Orange
12G 76 mm 2.8 mm 449 ml/min Light Blue
10G 76 mm 3.4 mm 609 ml/min Beige
